ELV-7A Power Amplifier

  • Karaoke
  • Professional
  • Power Amplifier
  • This series of power amplifier is specially designed according to Hi-Fi standard for ELV series speaker cabinet, the high power transistors are divided into left and right groups for improving the heat dissipation

  • Adopts metal housing transistor(excellent stability, heat dissipation and sound quality) and high quality components, wide sound field, clear LF/MF/HF, detailed and bright sound effect

  • ELV-7A power amplifier(700W*2CH) matches with ELV-151 speaker cabinet

  • It automatically shuts down the pre-noise when there is no signal and optimizes the sound effect according to the actual requirement based on the speaker cabinet features

  • Adjustable 70Hz gain knob is designed on the rear panel for boosting the bass

  • The front metal grille is fixed by magnets for easy dust cleaning

  • Designed with Class AB circuit, each channel circuit is internally bridged (equals to dual built-in Class AB circuits) to amplify the output power, so the output can not be brid

Product Detail

• Rated Power(8Ω):650W
• Rated Power(4Ω):900W
• Damping Factor:400:1
• S/N Ratio:>100dB
• THD:≤0.1% @1kHz
• Frequency Response:20Hz-20kHz +/-0.3dB
• IMD:≤0.2% 8Ω1KHz@1W
• Input Sensitivity:0.775V
• Input Impedance:15k/30k,balanced,unbalanced
• Power Supply:220V/50Hz
• Weight(Kg):23Kg
• Dimension(mm):483X132X407mm
• KTV, bar
