EKS-152 Full Range

Karaoke
Professional
Speaker Cabinet

EKS-152 uses dual HF units, one 51mm Ti diaphragm CCA winding HF unit and one 34mm Ti diaphragm tweeter to endure the high power operation
34mm HF unit mainly compensates HF and ultra HF to offer bright, delicate tone and to extend the vocal range.
Ti diaphragm features light weight, high strength, high anti-erosion capacity, anti- high-temperature, anti-low-temperature, anti-acid, anti-alkaline
The speaker cabinet features clear bass and clear vocal, and uses acoustic foam and vented hole to improve bass clearness
The trapezoid enclosure eliminates standing wave,18mm plywood cabinet with black paint for anti-moisture，4 handles for easy transportation，4 pin speaker connector, 4 feet for anti-vibration

Product Detail

Application
Specification

Indoors/outdoors small show, auditorium; multiple EKS-152 equipped with EKS subwoofer can be used for large show

• Rated power：900W
• Peak power：3600W
• Rated impedance：4Ω
• DC impedance：3.6Ω
• Frequency response：45Hz-18KHz(±3dB)
• Sensitivity：101dB
• Coverage：H100°×V 55°
• Max SPL：130dB
• Crossover mode： 3 way passive
• Crossover frequency：500Hz（LPF），1900Hz（ML,treble 1），2500Hz（treble 2 HP）
• Suspension/installation：suspension/pole mounting
• Connection：1×NL4 speaker connector，connect 1+,1- or 2+,2-. Parallel connection
  is not recommended.
• Enclosure：18mm plywood
• Finish：black painting
• HF1：2″×1(51mm，26mm throat)，140 magnet
• HF2：1.35″×1(34mm，26mm throat)，100 magnet
• LF：15″×2(75mm)，190 magnet
• Dimension（mm）：500×500×1200（W×D×H）
• Weight（Kg）： approx. 53.9 Kg
