EKS-121 Full Range

  • Karaoke
  • Professional
  • Speaker Cabinet
  • EKS-121 full range speaker uses 120 magnet 44mm PI diaphragm and Al winding HF unit, the HF unit can stand high power operation for a long time, natural and clear tone, accurate phase and flat frequency response after matched with subwoofer.

  • PI HF refractory diaphragm stands 290℃ for a long time and 490℃ for a short time, it features excellent mechanical and electrical performance, durable and fireproof.

  • EKS-121 uses built-in 2 way crossover and plane wave guide technology, the sound wave phase delay transmission and sound wave phase inversion overlaps for solving the phase distortion.

  • High sensitivity, charming tone, clear & rich vocal, bright MFHF.

  • The woofer uses 65mm Al winding for light weight and high efficiency. Symmetric magnet circuit design reduces the second harmonic distortion.

  • Trapezoidal enclosure eliminates standing wave inside.

  • 18mm MDF enclosure with black painting finish for anti-moisture.

  • Designed with a handle for convenient transportation and Al socket for convenient pole mounting.

  • Multiple flying points for flexible applications.

Product Detail

  • Specification
  • Application
• Rated power:350W
• Peak power:1400W
• Rated impedance:8Ω
• DC impedance:4.9Ω
• Frequency response:50Hz-18KHz(±3dB)
• Sensitivity:96dB
• Coverage:H100°×V 55°
• Max SPL:125dB
• Crossover mode:2 way passive
• Crossover frequency:2100Hz
• Suspension/installation:suspension or pole mounting
• Connection:1×NL4 speaker connector,connect 1+ ,1- for operation, 2+, 2- for
  speaker parallel
• Enclosure:18mm MDF
• Finish:black painting
• HF:1.75″×1(44mm,26mm throat),120 magnet
• LF:12″×1(65mm),170 magnet
• Dimension(mm):375×370×615(W×D×H)
• Weight(Kg):approx  22.7 Kg
Multifunctional hall, conference hall, theater, stage monitor, KTV installation
