MT5 Powered Studio Monitor
- Public Address
- Professional
- Speaker Cabinet
• Tailored for recording,the effect reaches professional level in studio
• Stereo boost effect benefits your comfort in listening
• Accurate EQ adjustment for flat frequency response
• Silk dome tweeter provides quick transient response, treble details and clear sound
• Poplypropylene woofer provides powerful bass dynamic response
• Adjustable acoustic filtering design optimizes monitoring effect
• High frequency filter boosts or decays relative frequency band to adjust sound brightness
• Custom designed internal reinforce ribs, high durability of professional MDF cabinet
• Acoustic foam eliminates noise for better sound field
Product Detail
- Product Detail
- Application
- Specification
- Product Content
- Product Tutorial
• Monitoring during professional recording, music appreciation
• Power Amplifier：Class AB dual power amp • HF：1 inch silk dome tweeter • LF：5.25 inch PP cone • HF Power：4Ω 20W/40W（peak） • LF Power：4Ω 30W/60W（peak） • Frequency Response（±3dB）：57Hz-20kHz • Crossover：24dB/octave＠2KHz • Max Peak SPL（one couple）：108dB SPL＠1m/1w • Input Adjustment：HF, LF 3 band adjustment • Input Connector：1*1/4“TRS,1*XLR,1*RCA • EQ： HF filtering sound space • Weight：4.7KG(net) • Dimension：180mm*220mm*280mm（WxDxH）
CONTENTS
| • Monitor speaker | 1pc |
| • Power Cord | 1pc |
| • User manual | 1pc |
PACKAGING
Export carton
User manualMT5 Active Studio Monitor User Manual2020-08-17 10:40:08Download
User manualMT5
