OPS-25 Portable Speaker Cabinet

  • Speaker Cabinet

Tailored for outdoor performance, personal performance, small party, program rehearsal;

Two 6.5 inch high performance cone speaker cabinets, high output volume, powerful full range stereo;

One XLR mic input and one guitar input connector for convenient singer performance;

Independent EQ and reverb and delay adjusting function to suit for microphone or instrument in different applications;

Trapezoidal enclosure design and socket for stage reinforcement or stand mounting;

Compact and portable design and solid structure and bag supplied for convenient outdoor application;

Use iPhone/iPad for recording or live broadcast via cell phone connector;

Built-in 2500mAh Li-ion battery, low power consumption, more than 6h operation.

Product Detail












Updated Version












Speaker cabinet specification
• Speaker: 6.5 inch *2(woofer),1 inch*1(tweeter)
• Frequency response:100Hz-15kHz
• Rated Power:24W
• Peak Power:40W
• Distortion:<1%
• AUX Input Sensitivity:0.775V,frequency range:20Hz-15kHz
• MIC Input Sensitivity:45mV,frequency range:200Hz-15kHz
• GUITAR Input Sensitivity:100mV,frequency range:200Hz-15kHz
• Operation Temperature:-10℃~45℃
• Dimension:420X215X280mm(D * W * H)
• Weight:approximate 6kg

Battery specification
• Type:Li-ion battery
• Specification:11.1V/2500mAh
• Charging: DC 12V/2A
• Operation Time: approximate 6h
• Charging Time:approximate 2.5h
outdoor performance, personal practice, small party, program rehearsal
• OPS-25 speaker cabinet   1pc
• Wired   microphone  1pc
• Microphone   cable   1pc
• Power   adapter   1pc
• Bag  1pc
• User   manual    1pc

Remarks:Simple version without wired microphone and microphone cable

  • User manual

    OPS-25 portable speaker cabinet2020-03-18 09:30:08Download
