EKV-121 KTV Speaker

Karaoke
Speaker Cabinet

12 inch 65mm cone woofer features soft bass and clear tone layers
MgAl diaphragm 44mm ferrite magnet tweeter, up to 90*90 degree horn directivity
PP horn and tweeter together achieve soft and delicate HF tone
The speaker cabinet endures wide dynamic power and keep stable performance for long time music playing
Glass fiber acoustic foam is used inside the cabinet to decrease the standing wave and increase the bass softness
The crossover uses MPT capacitor to extend the MF effect

Product Detail

Application
Specification
Product Content

KTV, bar

• Rated Power：300W
• Rated Impedance：8Ω
• Frequency Response：40Hz-19kHz（±3dB）
• Sensitivity：96dB
• Coverage：H90°×V90°
• SPL：121dB
• Crossover：two way passive
• Crossover Frequency：2000Hz
• Suspension/Installation：vertical or horizontal
• Connection：1×NL4speakon(IN1+,1-，LINK2+,2-)
• Enclosure：15+18mm plywood
• Finish：black painting
• HF：1.75″×1（44mm，26mm throat）110 magnet
• LF：12″×1（65mm）,170 magnet steel
• Dimension（mm）：370×380×610（W×D×H）
