【Takstar EKV-101 Audio System】Product Detail - Guangdong Takstar Electronic Co., Ltd.

EKV-101 KTV Speaker

Karaoke
Speaker Cabinet

EKV-101 consists one 10 inch 65mm voice coil woofer and one 36mm ferrite magnet steel HF with high polymer diaphragm, soft and delicate tone
The speaker cabinet endures wide dynamic power and keep stable performance for long time music playing
Glass fiber acoustic foam is used inside the cabinet to decrease the standing wave and increase the bass softness
The crossover uses MPT capacitor to extend the MF effect

Product Detail

Application
Specification
Product Content

KTV, bar

• Rated Power：200W
• Rated Impedance：8Ω
• Frequency Response：65Hz-19kHz（±3dB）
• Sensitivity：94dB
• Coverage：H80°×V60°
• Max SPL：117dB
• Crossover：two way passive
• Crossover Frequency：2300Hz
• Suspension/Installation：vertical or horizontal
• Connection：1×NL4speakon (IN1+,1-，LINK2+,2-)
• Enclosure：15mm plywood
• Finish：black painting
• HF：1.4″×1（36mm，25mm throat）90 magnet steel
• LF：10″×1（65mm），156 magnet steel
• Dimension（mm）：325×298×500（W×D×H）
