EPO-802 Peripheral Equipment

  • Peripheral System
  • Designed with voltage display on the front panel for voltage stability real time monitoring

  • Automatically and sequentially turning on/off via the switch on the front panel

  • LED indication for each channel operation, independent switch control for each channel

  • Standard USB interface provides 5V power supply

  • An additional strong power socket on the front panel for convenient power supply of live application

  • 3 pin output sockets for wide applications

  • High quality relays for long service life

Product Detail

  • Specification
  • Application
  • Product Content
• Input Power:AC 220V/50Hz
• Load Capacity:total 220V,30A;each channel output current 10A
• Input Power Cord:3×6mm2 pure copper RVV cable
• Controlled Channel:8 channels
• Standby Socket:1pc
• Socket:3pin socket (pure phosphor bronze)
• ON/OFF LED: 8 LEDs(red), one for each channel
• Input Power LED:one LED(green)
• USB Interface:1 (5V)
• Sequential Interval:2 seconds
• Dimension(W×D×H):440mm×215mm×48mm
• Weight:4.45Kg
Conference room, multi-function hall, KTV bar, project installation, outdoor activity
EPO-802 power sequencer 1pc
User manual1pc
