• Flexible connectivity: optical, coaxial, wireless, USB, RCA inputs.
• Powerful ADI digital audio processing.
• 7-band PEQ stereo EQ on music channel, auto-detect USB digital input.
• Mic noise cancellation, independent compression, 3-stage feedback suppression.
• Effects channel with high/low pass, reverb, 3-band PEQ.
• 7-band PEQ for mic, professional digital reverb for vocals.
• 3-5 band PEQ, mix, polarity, limiting on each output.
• USB computer control with dedicated management software.
• Mic noise gate for conference use.
• 8 savable system presets, last state loaded on power-up.
• For various KTV installation projects.
Music Section: • Signal Sources: Optical, Coaxial, Wireless, USB, RCA • Input Level: 775mVrms • Frequency Response: 20Hz-20kHz • THD: <0.1% (1kHz) • SNR: >80dB • PEQ: 1-7 bands Center Channel (CEN): • Input Level: 775mVrms • Frequency Response: 20Hz-20kHz • THD: <0.003% (1kHz) • SNR: >80dB • PEQ: 1-5 bands Subwoofer (SUB): • Input Level: 775mVrms • Frequency Response: 20Hz-400Hz • SNR: >80dB • PEQ: 1-3 bands Mic Section (3 Inputs): • Input Level: 50mVrms • Frequency Response: 20Hz-20kHz • THD: <0.1% (1kHz) • SNR: >80dB (direct) • PEQ: 1-7 bands Surround Channel (SUR): • Input Level: 775mVrms • Frequency Response: 20Hz-20kHz • THD: <0.003% (1kHz) • SNR: >80dB • PEQ: 1-5 bands Other: • Computer Connection: USB • Power Supply: AC200V-240V/50Hz • Fuse: T1A/250VAC • Power Consumption: 10W Note: The above data are measured by Takstar laboratory which has the final interpretation right!
• Processor | 1 PC |
• Remote Control | 1 PC |
• Power Cord | 1 PC |
• USB Data Cable | 1 PC |
• Antenna | 1 PC |
• User Manual | 1 PC |
EKX-2A Preamp Effects Processor User Manual2025-03-24 15:28:09Download
