XR-208 Mixer Console

  • Mixer
  • Wide dynamic range, low self noise and low distortion

  • Use famous ALPS potentiometer for low noise and high stability

  • Built-in +60dB low noise microphone preamplifier and 48V phantom power supply

  • 3-band equalizer for high, and low frequencies makes pleasant tone

  • Can be connected to an external effects device

  • Rugged and durable metal housing

Product Detail

  • Specification
  • Application
Stereo inputs
• Impedance: approx.20kΩ
• Max. input level: +20dBu
EQ stereo channels
• LOW: 80Hz/±15dB
• MID: 2.5kHz/±15dB
• HIGH: 12kHz/±15dB
Aux sends
• Impedance: approx.110Ω
• Max. output level: +20dBu
• S/N ratio: 110dB
• Total harmonic distortion: 0.01%
Stereo aux returns
• Impedance: approx.20kΩ balanced/ 10k unbalanced
• Max. input level: +20dBu
Main output
• Impedance: approx.110Ω unbalanced
• Max. output level: +20dBu
Mono inputs
Microphone inputs
XLR connector, electronically balanced, discrete input circuit
• Gain range: +10 to +50dB
• Max. input level: +10dBu
• Impedance: approx.2.2kΩ balanced
• S/N ratio: 110dB
• Total harmonic distortion: 0.01%
Line input
• Impedance: approx. 20kΩ balanced/10kΩ unbalanced
• Gain range: +10 to +30dB
• Max. input level: +20dBu @ 0dB gain
• Frequency response: 20Hz-20kHz+0dB/-3dB
• S/N ratio: 110dB
• Total harmonic distortion: 0.01%
• Net Weight: 1208g
Audio making, conference, on-stage performance
