• 3rd-generation high-performance DSP with SIMD core, 266MHz/40-bit floating-point processing, and 24bit/48kHz high-grade ADC/DAC for exquisite sonic details and rich audio expression.

• 12 input channels: 8 Mic/Line analog preamps with XLR female and ¼" TRS connectors, 1 stereo input, 1 USB Media stereo for USB playback, wireless playback or PC sound card.

• All Mic/Line channels are equipped with professional preamps featuring high dynamic range and low distortion for precise signal matching.

• Mic/Line channel processing: 48V phantom power, phase inversion, noise gate, compressor, 4-band parametric EQ (PEQ), high-pass filter (HPF), low-pass filter (LPF).

• All output channel processing: delay, 4-band parametric EQ (PEQ), high-pass filter (HPF), low-pass filter (LPF), compressor.

• Built-in professional DSP effects (FX) with 5 types: Echo, Reverb, Echo+Reverb, Flanger, Stereo Delay, plus over 100 presets in total.

• Setup wizard, status indicators, Scenes, Presets and Copy-to functions simplify channel configuration, gain adjustment and effect selection. Scenes and presets can be stored/recalled internally or via external USB drive.

• High-resolution color capacitive touchscreen with graphical user interface and physical buttons for intuitive, efficient operation.

• Backlit tactile switches and precision 100mm motorized faders deliver smooth, responsive control feel.

• Wide universal voltage range (85–240Vac); auto pop elimination on power on/off, no switching thumps even without a power sequencer.

• USB Media playback supports MP3, AAC, WAV, AIFF, APE and FLAC formats. Direct recording to external USB drive without a computer.

• Plug-and-play USB wireless playback interface for wireless music streaming from mobile devices.

• High-fidelity 48kHz/24bit PC sound card with simultaneous recording and playback for easy live streaming.

• CH01 and CH02 support high-impedance instrument input; digitally controlled Hi-Z/Lo-Z switching, scene-synced and thump-free.

• Adaptive Auto Mix Control (AAMC) covers CH01–CH08 mics, ST-in, USB playback and PC sound card; auto-manages mics and background music with weight assignment and intelligent gain-sharing algorithm.

• Advanced Anti-Feedback Howling Suppression (AFHS) with dynamic suppression and 4-band notch filters, individually controllable for flexible, high-efficiency performance.

• Dedicated Overview interface displays the full signal path from input to output; click any node to adjust parameters directly.

• ISUeasy™ firmware upgrade via USB port for full system update (including MCU program), keeps the mixer up to date easily.

• LAN IP connectivity for wireless remote control via iPad (iOS) or Android tablet; the app controls nearly all mixer parameters wirelessly.

• Programmable central control via network port; accepts control commands with simple ASCII command language and flexible extensible syntax. Supports RJ-45 Ethernet and RS-485.

• RS-485 port with 5V/500mA power output, easily connects to multiple 86-type wall panel controllers for synchronous quick control.

• AUX1 and AUX2 output buses support fully independent pre-fader/post-fader routing; CH01–CH08 each feature individual pre/post-fader routing control.
