BM-621 Boundary Microphone

  • Conference & Speech
  • Wired
  • Boundary
  • Cardioid
  • Condenser
  • Monitoring
  • Noble electrophoretic finish

  • Quality cardioid capsule features long pick up distance and excellent sound

  • Capsense touching on/off switch design eliminates the mechanical noise of traditional switch

  • Advanced RFI shielding technology can avoid signal interference such mobile

  • phone signal when operating

  • Optional low frequency roll¡ªoff switch eliminates unwanted low frequency noise

  • 9V-52V phantom power supply

  • Professional MINI XLR output socket

Product Detail

  • Specification
  • Application
• Transducer Principle: Condenser
• DirectMty Characteristic: Cardioid
• Frequency Response: 3OHz-2OkHz
• Low Frequency Roll-off: 6OHz-200Hz 10dB±2dB
• Sensitivity: -30dB±3dB(OdB=1V/Pa at 1 kHz)
• Equivalent Noise Level: 24dB A
• Max. Input Level: 13OdB(THD≤1.5% at 1kHz)
• Mute Switch: Capsense touching switch
• Output Impedance: 100Ω±30%(at 1 kHz)
• Power Requirement: 9-52V DC, 4mA typical
• Dimension: 100 x 73 x 24mm
• Conference sound reinforcement, on-location broadcasting
  • Specification
  • Application
• Transducer Principle: Condenser
• DirectMty Characteristic: Cardioid
• Frequency Response: 3OHz-2OkHz
• Low Frequency Roll-off: 6OHz-200Hz 10dB±2dB
• Sensitivity: -30dB±3dB(OdB=1V/Pa at 1 kHz)
• Equivalent Noise Level: 24dB A
• Max. Input Level: 13OdB(THD≤1.5% at 1kHz)
• Mute Switch: Capsense touching switch
• Output Impedance: 100Ω±30%(at 1 kHz)
• Power Requirement: 9-52V DC, 4mA typical
• Dimension: 100 x 73 x 24mm
• Conference sound reinforcement, on-location broadcasting
