SM-8B Side-address Microphone
- Recording
- PC & Cell Phone Karaoke
- Wired
- Cardioid
- Condenser
- Side Address
High sensitivity, low self noise
High-performance back electret condenser capsule
Built-in transistor circuit, low self noise and stable performance
Wide frequency response
Product Detail
- Application
- Specification
- Product Content
- Product Tutorial
• Broadcast recording, personal recording, instrument recording, live performance
• Transducer Principle: Back Electret Condenser • Directivity Characteristic:Unidirectional • Frequency Response: 20Hz-20kHz • Sensitivity: -33dB±3dB (0dB=1V/Pa at 1KHz) • Equivalent Noise Level: ≤22dB (IEC 581-5) • Max. Input SPL: 130dB (THD ≤1.0％ at 1kHz) • Output Impedance: 200Ω±30% (at 1kHz) • Power Requirements: 48V DC Phantom Power • Body Dimensions:∅54mm*L148mm • Net Weight:356g Note: The data is tested by Takstar Laboratory and Takstar has the final interpretation right!
| • Microphone | 1 PC |
| • Microphone stand | 1 PC |
| • Microphone windscreen | 1 PC |
| • User Manual | 1 PC |
User manualSM-8B Side-address Microphone User Manual2022-08-31 16:31:23Download
User manualSM-8B
