EA-3 Power Amplifier

Power Amplifier

• Class-AB design with toroidal power supply.

• Analog amplifier, featured by enjoyable sound, delicate MFHF and punchy LF.

• Precise gain controls, power/signal/protection/clip LEDs on the front panel.

• DC/thermal/over-load/limiter protection circuit design on each channel.

• Rear-to-front fan cooling for prolonged and reliable operation.

• Balanced XLR input connector and pro SPEAKON output connector.

• Toggle switch on the rear panel to select Stereo/Parallel/Bridge mode.

Product Detail

Specification
Download

• Rated Output Power (1KHz, 1% THD)
Stereo 8Ω：330W+330W
Stereo 4Ω：500W+500W
Bridge 8Ω：1000W
• Peak Power（1KHz1%THD）
Stereo 8Ω：660W+660W
Stereo 4Ω：1000W+1000W
Bridge 8Ω：2000W
• Output Connector：Binding for Stereo & Bridge Output
• Frequency Response：20Hz-20KHz
• Input Sensitivity：1.0V; 1. 4V
• Input Impedance (bal/unbal)：20k   /Balanced,10k   /un-Balanced
• S/N Ratio：100dB
• Distortion：<0.03%（8ohm/1KHz/half power）
• Crosstalk (at rated output power, 1KHz, 8 Ohms)：80dB
• Damping Factor (1KHz, 8 Ohms)：300
• Conversion Rate：20 V/uS
• Protection：Soft Start,Short Circuit,Limiter,DC Fault,AC Line Fuse,Thermal Cut
• Cooling System：Two steps speed fan
• Power Requirement：AC:220-240V    50Hz
• Net Weight (kg)：12.4kg
• Dimension (W*D*H)：483x88x410mm
