PC-K600 Side-address Microphone

  • Recording
  • PC & Cell Phone Karaoke
  • Wired
  • Cardioid
  • Condenser
  • Side Address
  • Gold-plated, 0.4 micron ultra thin and Ø34mm large diaphragm ensure exquisite and accurate sound reproduction

  • Switchable bass filter to eliminate unwanted low frequency noises

  • Switchable 10dB attenuation for improving the sound fidelity and eliminate environmental noise

  • Adopts patent WPH Restrain 180°™ 3-layer wire mesh noise filter technology, the breathing and wind noise at 180°can be effectively filtered

  • Supplied with professional microphone amplifier which features high gain, switchable and adjustable reverberation effect

  • Supplied with metal shock mount, cable and table stand

Product Detail

  • Specification
  • Application
Microphone Specification
• Transducer Principle: true condenser
• Directivity Characteristic: cardioid
• Frequency Response: 20Hz-20kHz
• Sensitivity: -36dB±3dB (0dB=1V/Pa at1kHz)
• Output Impedance: ≤100Ω (at 1kHz)
• Load Impedance: ≥1000Ω
• Equivalent Noise Level: ≤10dB (IEC 581-5)
• Max. Input SPL: 140dB (THD ≤1.0% at 1kHz)
• Output Connector: XLRM
• Power Requirement: 48V phantom power
• Body Dimension: 50 mm x 188mm (diameter x length)
• Net Weight: 480g
Microphone Amplifier Specification
• Compatibility with Microphone: dynamic/condenser microphone
• Phantom Power: +48V
• Input Connector: standard XLR, balanced input
• Output Connector: standard XLR, balanced output
• Gain Range: 0-40dB stepless adjustment
• S/N Ratio: ≥100dB (GAIN=10)
• Frequency Response: 20Hz-50KHz±0.2dB
• Total Harmonic Distortion: 0.002% (GAIN=10)
• Signal Level Indication: by seven LEDs
• Power Supply: AC15V/500mA
• Net Weight: 433g
Recording, chat room, broadcasting
