XR-1824FX Mixer Console

  • Mixer
  • 18 XLR and TRS balanced inputs

  • 6 stereo TRS balanced inputs

  • Low noise preamplifier and +48V phantom power

  • Each channel has SUB1-2, SUB3-4 and MAIN L-R signal distribution switch

  • Each channel has 4 aux sends: AUX1/AUX2 sends with PRE/POST switch are used to monitor the operation effect and sound processor input, whether controlled by fader or not is to switch the PRE/POST switch; additional aux sends DFX1 and DFX2 are used to monitor the external or internal DSP effect when it is set at the post of the fader

  • Mono channel has 3 band EQ with adjustable MF, stereo 4 band EQ

  • Insert connector and direct output connector for each mono channel, together with the main insert connector, it can connect with the external equipment flexibly

  • CD/Tape IN can be assigned to the main output and monitor/headphone output

  • USB interface, 9 band GEQ

  • Built-in 24 bit effecter equipped with 100 presets, effect mute and peak LED

Product Detail

  • Specification
  • Application
• 18pcs gold plated XLR and balanced 6.3mm mono input channel,with HPF
• With gain and +48V phantom power for mono input channel
• 6 stereo input channels with 6.3mm connector and level selection switch
• Two effectors with 99 effects
• Output signal has 9 band GEQ
• 6 band EQ with MF scanning for mono input channel
• 4 band fixed EQ for stereo input channel
• 6 AUX outputs:AUX1 is with pre/post fader for foldback; AUX6 post fader
  is used for sending effects
• Each input channel is with MUTE/ALT1-2/ALT3-4,SOLO switch, signal LED
  and overload LED
• 4 stereo AUX returns have level controls and can send the signal to AUX1
• TAPE IN/TAPE OUT with shut-off switch for sending the signal to the control
  room and main output
• Matrix(MAIN MIX/1-2/3-4) and group output level are used for headphone/control room
• Balanced XLR and 6.3mm output connector
• Dimension:545*770*190mm
• Net Weight:14.4Kg
Home entertainment, commercial show, large assembly, outdoor activities
