SM-9 PROFESSIONAL RECORDING MICROPHONE-TAKSTAR - Guangdong Takstar Electronic Co., Ltd.

SM-9 Professional Recording Microphone

  • Recording
  • Hanging
  • Cardioid
  • Unidirectional
  • Condenser
  • Wired

• ø34mm gold-plated condenser capsule with wide frequency response, high dynamics and rich timbre.

• High sensitivity, precise pickup pattern, excels at vocal recording.

• Low self-noise circuit for studio level recording.

• High SPL processing capability to prevent overload distortion.

• Metal pop screen to better filter out plosives and airflow noise.

• Excellent shock mount for absorbing vibrational noise.


Product Detail

• Capsule: ø34mm, gold-plated, condenser
• Polar Pattern: unidirectional
• Frequency Response: 20Hz-20KHz
• Sensitivity: -32dB±3dBV (0dB=1V/Pa at 1KHz)
• Equivalent Noise Level: ≤23dBA
• Peak SPL: 135dB (THD≤0.5% at 1KHz)
• Output Impedance: 110Ω±30% (at 1KHz)
• Power Supply: 48V phantom power
• Mic Dimensions: ø51mm*184mm
• Mic Weight: about 440g
Note: The above data are measured by Takstar laboratory, and Takstar has the final interpretation right!
• Studio recording, web broadcast.
• Microphone1 pc
• Shock Mount1 pc
• Elastic Band2 pcs
• Pop Screen1 pc
• Windscreen1 pc
• User Manual1 pc

*PACKAGING:Color box,(L*W*H)316*236*132mm

  • User manual

    SM-9Professional Recording Microphone User Manual2023-07-13 14:53:13Download
