TPM-1 Power Supply

  • Power Supply
  • Stable multi-voltage rectified filtering circuit effectively eliminates AC signal interference

  • Two balanced power inputs/outputs assure stable voltage and effective common mode interference rejection

  • Noiseless 0n/Off switch

  • External power adaptor avoids electromagnetic interference

  • Built-in low pass filter eliminates unwanted noise from external audio equipment

Product Detail

  • Specification
  • Application
  • Product Content
• Phantom Power Supply: +48V
• Input Power: AC 18V 300mA
• Output Voltage: DC 48V
• Power Consumption: ≤5W
• Noise: ≤1.8uV
• Input Connector: Standard Cannon XLR, balanced input
• Output Connector: Standard Cannon XLR, balanced output
• Dimension: 90.3×98×41.8mm(L×W×H)
• Net Weight: 242g
Recording, chat room and broadcasting
Power Adapter1pc
Packing: Blister + color box
