TS-3380 Wireless Microphone

  • Performance
  • Conference & Speech
  • Wireless
  • UHF
  • Karaoke

• High-performance UHF integrated circuit, multiple frequency channels selectable, better stability and nook coverage

• Special channel ID code (tone-key) function effectively prevents crosstalk

• Intuitive work status overview on LCD display

• One-key scan function on receiver automatically finds the best available channel

• IR sync to easily sync transmitter and receiver in one easy press

• Standalone balanced XLR outputs, plus mixed unbalanced 6.3mm output.

Product Detail

• Frequency Range: 610-680MHz
• Frequency Stability: ± 10ppm
• Sensitivity: 10dBuV
• Adjacent Channel Rejection: 65dB
• Image Frequency Rejection: 75dB
• Audio Output: 200mV
• Output Impedance: XLR connector: 200Ω;   1/4" connector: 1K
• S/N Ratio: 100dB
• Distortion: <0.1%
• Frequency Response: 50Hz-18KHz
• Receiving Distance: 100 (m)
• Function Display: LCD
• Power Supply: DC=12V
• Dimension: 480*180*45mm
• Weight: approx. 1450g
• Material: iron case, aluminum panel

• Frequency Range: 610-680MHz
• Frequency Stability: ± 10ppm
• Transmit Power: 10mW
• Receiving Distance: 100 (m)
• Harmonic Suppression: >65dB
• Modulation: FM
• Max Modulation Degree: 75K
• Operating Voltage: 3V
• Operating Current: 120mA
• Function Display: LCD
Note: The above data is measured by Takstar laboratory.
• Classroom, KTV, conference, family entertainment and outdoor performance
• TS-3380 Receiver1 pc
• Audio Output Cable1 pc
• Power Adapter1 pc
• Handheld Microphone2 pcs
• AA Battery4 pcs
• Mic Anti-Roll Ring2 pcs
• User Manual1 pc

  • User manual

    TS-3380 Wireless Microphone User Manual2023-07-07 17:07:39Download
