TS-816V Conference System

  • Conference System
  • Balanced/unbalanced 16 channel combo input, supports microphone or line input, with independent gain input control knob

  • Camera PTX control port (support VISCA/PELCO_D/P protocol) for conference camera automatic tracking

  • Four camera inputs, automatic video output signal switch and multi-position video without dead-corner suits for video conferencing with multiple participants

  • 3 units can be combined and used together, user can increase the quantity of host unit according to the actual application

  • With speak restriction mode, FIFO, the simultaneous speaking number can be set to effectively reduce the howling and enhance the conference quality

  • Intelligent voice control function, when the voice is detected and exceeds the set threshold, the microphone will turn on automatically

  • Chairman channel is always defaulted as channel 1, which is not restricted by the speech mode

  • Provided with switchable 48V phantom power supply

Product Detail

  • Specification
  • Application
  • Product Content
• Peak input level:≥ -7dBV(Unbal), -13dBV(Bal), +10dBV(Aux)
• Peak output:≥ +8dBV
• S/N ratio:93dB(A weighted)
• Phantom power:+48VDC
• Power supply:18V/2A
• Frequency response:30Hz - 70kHz
• Camera protocol:VISCA/PELCO_D/P
• Camera connector:RS-422/485 (one way control)
• Camera baud rate:9600bps
Conference, recorded broadcast, monitor
  • Chairman unit
1pc
  • Connection cable
1pc
  • Power adapter
1pc
  • Package
color box
