TS-808 Conference System

  • Conference System
  • 8-channel automatic mixer with high S/N ratio and clear, natural sound quality

  • Advanced microprocessor controlled circuitry

  • Capable of linking systems containing several mixers

  • Optional control for principal mode, FIFO mode, free mode

  • Additional line input for backgroud music

  • Balanced microphone output

  • Additional line output for recording system

  • Powered by 48V phantom power supply, separate power switchs for channel 1-4 and channel 5-8

  • High output level for synonous tracking of the camera and indicator

  • Can be used as common mixer while switching to the manual mode

  • Headphone monitoring function available

  • Optional 10dB attenuation on ecah channel for different applications

Product Detail

  • Specification
  • Application
• Max. Gain: >73dB
• Frequency Response: 30Hz-20kHz
• Equivalent Input Noise: -124dBV
• Mic Input Attenuation: 10dB
• Power Supply: +48V
• Control Voltage Output: +48V
• Power Requirements: 15V/800mA
• Input Impedance: 4000Ω ( Balanced)
• Output Impedance: 300Ω ( Balanced)
Conference system
