• Utilizes embedded PC tech, DSP audio processing, and industrial-grade ARM chip for rapid startup and enhanced stability.
• Dual-channel amplifier (2*20W/8Ω) with built-in network audio decoding.
• Independent IP address, receives custom scheduled broadcasts directly from the server.
• Delivers high-fidelity CD-quality digital audio with an adaptive bitrate of 32-320kbps, ensuring noise-free playback.
• Independent volume and balance adjustments, plus digital treble and bass controls for precise sound tuning.
• Supports handheld and network mics for two-way communication and broadcasting to specified terminals.
• RS232 interface for connection and control of additional devices.
• Expandable audio capture function to transmit on-site audio back to central control room for real-time monitoring.
• Offers 1CH stereo line input and 1CH mic input for external audio sources with adjustable volume.
• Wooden exterior for aesthetic appeal and high-fidelity audio quality.
• With power and data indicator lights for easy device status monitoring.
• Master speaker includes an auxiliary output for connecting a secondary speaker.
• Expandable 110V signal input, auto switchable to constant voltage mode in case of IP network or speaker power failure, for dependable performance during critical periods.
• Remote software-based bass and treble adjustments to tailor to playback content.
• Smart Power Management, auto sleep mode during inactivity, maintaining low standby power (≤0.2W) and waking for playback tasks.
• Remote volume control, auto adjust volume (BGM, emergency, fire alarm) to pre-set system levels upon automatic startup and playback tasks.
• Receives diverse broadcast programs over the network, including intercom and emergency alerts.
• Single-cable solution, leverages existing network infrastructure, compatible with TCP/IP for seamless integration across broadcasting, computing, and monitoring systems.
• Remote network update support for easy maintenance.
• IP reset switch to restore factory settings.
• Shopping malls, campuses, hotels, parks, prisons, community announcements, and large commercial complexes.
SG-540W1 • Network Interface: RJ45, 10M/100M • 110V Signal Input (optional) • 2.4G Wireless Module (optional) • Network Protocols: TCP/IP, UDP, ICMP, IGMP (multicast) • Audio Formats Supported: MP3, MP2 • Bitrate Range: 32K-320K • Frequency Response: 20Hz - 20KHz • Sensitivity: 95dB • SNR: Line: ≥90dB; Mic: ≥88dB • Rated Power: Stereo 2*20W; Max Power 2*30W; Industrial standard terminal • Power Supply: AC 220V ±10%, 50-60Hz / External DC 12V/5A (optional) • Speaker Impedance: 5": 8Ω; 2.5": 8Ω; with crossover • Speaker Units: 1*5" + 1*2.5" • Standby Power: 0.2W • Weight: Approx. 3KG • Dimensions: 200mm (H) * 170mm (W) * 330mm (D) • Installation: Wall-mounted or tabletop SG-540W2 • Rated Power: 20W; Max Power: 30W • Speaker Impedance: 5": 8Ω' 2.5": 8Ω; with crossover • Speaker Units: 1*5" + 1*2.5" • Dimensions: 330mm (H) * 200mm (W) * 170mm (D) • Installation: Wall-mounted or tabletop Note: The above data are measured by Takstar laboratory which has the final interpretation right!
| • Speaker | 1 PC |
| • Power Cord | 1 PC |
| • User Manual | 1 PC |
User manualSG-540W1/W2 IP Active Speaker User Manual2026-05-18 09:30:52Download
